Bleeder stack
Bleeder stacks of DN250 and DN400 types are designed to discharge gas from the dust collector into the atmosphere. The bleeder stacks are installed on vertical sections of the gas bleeders.
Bleeder stack of DN800 type is designed to discharge gas from the dust collector into the atmosphere.
The furnaces are usually equipped with two such bleeder valves installed in the upper parts of the gas bleeders.
The bleeder stack consists of the following main units: housing, seat, shutoff plate, driven shaft, regulator. The stacks are opened with a separate electric winch. The shutoff plate is pressed to the seat of the stack with the counterbalance.
Manufacturing period: 60 days.
