Charging machine
Charging machine is designed to move the hot-metal and slag ladle formations around the furnace and perform maneuvering operations at the working railway section.
The charging machine consists of: bearing frame; driven running wheels; cab; electric drive; remote control system; automatic coupler.
Main advantages:
- no necessity to use additional gears at stopping of the formation during the casting process;
- high serviceability.
The charging machine is supplied with a tension winch for the rope bearing the electric cables or without a winch.
Manufacturing period: 120 days.
