Fume valve
Fume valve is designed to shutoff the stove from the intake of the fume pipe during the air heating as well as to withdraw the combustion products from under the stove to the chimney.
The fume valve consists of: housing, cover, plate and cooled seat.
The plate is connected with the regulator through the joint. The driven sector is hardly landed on a single axle with the regulator and is connected with the winch through the rope.
The valves may be produced either right or left according to the drive position.
Manufacturing period: 150 days.
